China Lithium-ion Battery Manufacturer Customize Battery for Brain Imaging System UFX 523450 1000mAh 3.7V Lipo Battery with KC Certification

$1.60
In stock
SKU
BZ 523450

FOB Price: US $1.2 - 1.5 / Ampere
Min.Order Quantity: 1000 Ampere/
Please contact us for the order !

  •     Place of Origin: Guangdong, China
        Brand Name: UFX
        Model Number: 523450
        Type: Li-polymer
        Nominal Voltage: 3.7V
        Size: 5.2*34*52mm
        Nominal Capacity: 1000mAh
        Product name: 523450 Li-ion battery
        Warranty: 1 Year
        Weight: 18g
        Cycle life: 500 Times
        Capacity: 1000mah
        Voltage: 3.7V
        Application:
    Brain Imaging System Battery
        Certificate: CE/RoHS/UN38.3/MSDS
        Payment: Paypal.TT.Escrow.Western Union
        Max charge current: 1C

Battery for Brain Imaging System BZ 523450 1000mAh 3.7V Lipo Battery with KC Certification

ufx 523450 1000mAh 3.7V Lipo Battery with KC Certification

BZ 523450 1000mAh 3.7V Lipo Battery523450 1000mAh 3.7V Lipo Battery1000mAh 3.7V Lipo Battery

1000mAh Lipo Battery with KC Certification

1000mAh Battery for Air Cleaner

Product Parameters

No.

Item

General Parameter

Remark

1

Rated Capacity

Typical

1050mAh

Standard discharge(0.2C C5A) after Standard charge

Minimum

1000mAh

2

Nominal Voltage

3.7V

Mean Operation Voltage

3

Voltage at end of

3.0V

Discharge Cut-off Voltage

Discharge

4

Charging Voltage

4.2±0.03V



5

Internal Impedance

≤40mΩ

Internal resistance measured at AC 1KHZ after 50% charge

The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times

6

Standard charge

Constant Current 0.2C5A

Charge time : Approx 6h

Constant Voltage 4.2V

0.01 C5A cut-off

7

Standard discharge

Constant current 0.2 C5A



end voltage 3.0V

8

Fast charge

Constant Current 0.5C5A

Charge time : Approx 2.5h

Constant Voltage 4.2V

0.01 C5A cut-off

9

Fast discharge

Constant current 0.5C5A



end voltage 3.0V



10

Maximum Continuous Charge Current

1 C5A



11

Maximum Continuous Discharge Current

1C5A



12

Operation Temperature Range

Charge: 0~45

60±25%R.H.

Bare Cell

Discharge: -20~60



13

Storage Temperature Range

Less than 1 year: -20~25

60±25%R.H.

less than 3 months: -20~40℃

at the shipment state

14

Pack  Dimension

High: ma52mm

Width: max34mm
Thickness: max5.2mm

Initial  Dimension
